HP-STD5300XG
HYPERVSN
| Specification for 5300 Lumen 3LCD Laser Projector | ||
| Model No./ Brand | HP-STD530XG | |
| Overall Spec | ||
| Panel | Brightness (Lumen) | 5300 |
| Resolution | XGA (1024 x768) | |
| Display Panel | 3x0.63" with MLA | |
| Display Technology | Liquid Crystal Display | |
| Light source Life time | Light Source | Laser (Nichia) |
| Normal mode | 20000hrs | |
| ECO mode | 30000hrs (TBD) | |
| Projection Lens | Lens Vendor | FUJIFILM |
| F | 1.7~2.11 | |
| f | 17.5~29.01mm | |
| Zoom/Focus | Manual | |
| Throw Ratio | 1.34~2.22: 1 | |
| Zoom Ratio | 1.66X | |
| D Zoom | 0~19 (0.0X~4.0X) | |
| Screen size | 30-300 inch (0.81~13.86m) | |
| CR | Contrast Ratio | 5,000,000:1 |
| Noise | Noise(dB) | TGT: 37dB (Normal)/ 27dB (ECO) |
| AR | Aspect Ratio | 4:3 (Standard)/16:9 (Compatible) |
| Terminal (I/O port) | ||
| Input | VGA | *1 |
| HDMI | *2 | |
| Composite Video | *1 | |
| Audio in (jack 3.5mm) | *1 | |
| Audio in (RCA×2) | *1 | |
| USB-A 2.0 | *1 | |
| USB-B 2.0 | *1 (Display) | |
| RJ45 | *1 (Display) | |
| Output | VGA | *1 |
| Audio out (jack 3.5mm) | *1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 | |
| LAN | *1 | |
| General Spec | ||
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter | |
| Filter Life Time | 7300h(TBD) | |
| Power Consumption | Power Requirements | 100~240V@ 50/60Hz |
| Power Consumption (Max) | 340W | |
| Standby Mode | <0.5W | |
| Temp. & Humidity | Operating Temp. | 5 to 40°C |
| Operating Thumidity. | 20-80% | |
| Storage Temp. | -10 to 50°C | |
| Storage Humidity. | 10-85% | |
| High altitude | 1700-3000m | |
| Other Functions | ||
| Keystone | Keystone Correction (Lens@center) | V: ±30°, H：±30°, 4 corner |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 24~85Hz | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA,WUXGA, 4K (3840 x 2160) @30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p,1080i, 1080p | |
| SW setting | Auto Setup | INPUT SEARCH, AUTO PC, Auto Keystone |
| Blank | Yes | |
| Suspend | Yes (5 minutes, no signal as default) | |
| Picture mode | Dynamic, Standard, Cinema, Colorboard, Blackboard (Green), User Image | |
| Cooling time | Normal, 30 Sec, 0 Sec | |
| Closed caption | Yes | |
| Auto Ceiling | Yes | |
| D-Zoom | 0~19 | |
| Others | 360° projection | Yes |
| Dimension & Weight | MAX Dimensions | WxDxH: 390*294*127mm |
| Net. Weight | 5Kg | |
| Packaging (WxDxH mm) | WxDxH: 492*443*239 | |
| Gross. Weight | ~6.5Kg | |
| Accessory | Manual Languages | Chinese, English |
| Standard Accessaries | Power cord, Remote control + Pin, HDMI Cable, VGA Cable | |
