HP-L430W
HYPERVSN
| Model No. | HP-L430W |
| Brightness | |
| Brightness | 4300 ANSI Lumens |
| Light source | Lamp: 225W |
| Overall Spec | |
| Display Panel | 3x0.64” |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WXGA (1280 x 800) |
| Lamp Consumption (W) | Philips: 225W Infinity (Lamp) |
| Lamp Lifetime (H) | 10000H (Normal) / 20000H (ECO) |
| Zoom/Focus | Manual |
| Throw Ratio | 70"@1.904m; 1.26~2.09:1 |
| F | F1.7x1.66 |
| f | f=17.5~29.01mm |
| Zoom Ratio | 1.66x optics |
| Screen size | 0.812~13.869m (30"~300") |
| Contrast Ratio (Min) | 20000:1 (w/IRIS) |
| Noise (dB)@1m | ECO: 30dB/ Normal: 37dB |
| Uniformity (Actual Min) -JISX6911 | 80% |
| Aspect Ratio | 16:10 (Standard)/ 4:3 (Compatible 16:9) |
| Terminal (I/O port) | |
| VGA in | *1 |
| HDMI in | *2 |
| Video in | *1 |
| Audio in (mini jack,3.5mm) | *1 |
| Audio in (L/R) -RCA | *1 |
| USB-A 2.0 | *1 |
| USB-B | *1 |
| RJ45 | *1 (Display) |
| VGA out | *1 |
| Audio out (mini-jack, 3.5mm) | *1 |
| RS232 | *1 |
| RJ45 | *1 (Control) |
| USB-B | *1 (for upgrade) |
| General Spec | |
| Speaker | 1*10W |
| Power Requirements | 100~240V@ 50/60Hz |
| Power consumption (W) | 310 |
| Power Consumption (ECO) | 217 |
| ECO Standby Mode | <0.5W |
| Network standby | <2W |
| Operating Temp. | 0℃~40℃ (35~ ECO) |
| Store Temp. | -10℃~~55℃ |
| Operating Humidity | 20%~85% |
| Storage Humidity | 10%~85% |
| Security bar | Yes |
| Password protections | Yes |
| Control Panel Lock | Yes |
| Kenginston Lock | Yes |
| Ventilation (In/Ex) | Side/Side |
| Lamp access | Top |
| Filter access | Side |
| Dust filter | ESD filter |
| Other Functions | |
| Keystone | V: ±30° (auto+manual) H: ±15° (manual) Pincushion Barrel Correction Corner Keystone |
| Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi |
| LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes |
| LAN Control-PJ Link | Yes |
| Scanning Frequency | H-Synch Range: 15~100KHz/ V-Synch Range: 48~85Hz |
Display Resolution Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac, |
Display Resolution Video Signal Input | NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N |
| Auto Setup | INPUT SEARCH, AUTO PC, AUTO Keystone |
| Audio muting(Muting) | Yes |
| Suspend | Yes (5miniutes, no signal as default) |
| Picture mode | Dynamic, Standard, Cinema, Blackboard, Colorboard |
| Lamp mode | NORMAL, ECO |
| Filter Cleaning Cycle | 100/200/300 hours |
| Cooling time | 0S, 60s, 90s |
| Closed caption | Yes |
| High altitude | Yes (1400~2700m) |
| Signal Power On | Yes |
| Turn on the countdown | Customized-(5S, 10S, 30S..) |
| Auto Ceiling | Yes |
| D-Zoom | 1~33 |
| Others | |
| Dimension&Weight | |
| MAX Dimensions (WxHxD) | 345*261*99 |
| Net. Weight (KG) | ~3.26 |
| Packaging Size (WxHxD) | 442(L) x 386(W) x 195mm(H) |
| Gross. Weight (KG) | 4.7 |
| Accessories | |
| Standard Accessories | Power cord, HDMI Cable, Remote control |
