MX-351XS
SMX
DESCRIPTION
The SMX MX-351XS mobile multimedia projector is designed to provide high brightness for small-to-medium-sized businesses, education environments, corporate conference rooms, and mobility applications where heavy ambient light is present but the space requires a small projector. This lightweight model is affordable and has essential features, including high brightness and color output and high-contrast images.
• 3LCD technologies for optimized color output compared to DLP types
• HDMI input connects you to high-definition sources
• Image Care technology helps extend lamp life and lowers power consumption
• Lightweight and practical
DESCRIPTION
The SMX MX-351XS mobile multimedia projector is designed to provide high brightness for small-to-medium-sized businesses, education environments, corporate conference rooms, and mobility applications where heavy ambient light is present but the space requires a small projector. This lightweight model is affordable and has essential features, including high brightness and color output and high-contrast images.
• 3LCD technologies for optimized color output compared to DLP types
• HDMI input connects you to high-definition sources
• Image Care technology helps extend lamp life and lowers power consumption
• Lightweight and practical
| Model | ||
| Model No. | MX-351XS | |
| Resolution | XGA | |
| Brightness | ||
| ISO | Brightness ( Ansi Lumens ) | 3500 |
| Overall Spec | ||
| Panel | Display Panel | 3x0.63” |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | XGA (1024x768) | |
| Projection Lens | Zoom/Focus | Manual |
| Throw Ratio | 60"@1.8m;1.47~1.77:1 | |
| F | F:2.1~2.25 | |
| f | f=19.109~22.936mm | |
| Zoom Ratio | 1.2x optics | |
| Screen size | 0.887~10.899m(30"~300") | |
| Contrast | Contrast Ratio(Min) | 15000:1 (w/o IRIS) |
| Noise | Noise(dB)@1m | ECO: 35dB Normal: 38dB |
| Uniformity | Uniformity(Actual Min) -JISX6911 | 80% |
| AR | Aspect Ratio | 4:3 (Standard)/16:9(Compatible) |
| Terminal(I/O port) | ||
| Input | HDMI | *2 |
| USB-A | *1 | |
| Control | RS232 | *1 |
| General Spec | ||
| Audio | Speaker | N/A |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power consumption(W) | 300 | |
| Power Consumption(ECO) | 250 | |
| ECO Standby Mode Power Consumption | <0.5W | |
| Cooling Set Up | Operating Temp. | 5℃~40℃(35~ ECO) |
| Store Temp. | -10℃~~50℃ | |
| Oparating Humidity | 20%~80% | |
| High altitude | 0 to 3000 m | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30°/ H:±30° 4 corner (Manual) |
| OSD | Languages | 9 Languages: English / Chinese / Français / Español/ Português / 한국어 / Pусский / Tiếng Việt / ﺏﺎﻠﻋﺮﺒﻳﺓ |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 48~85Hz | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
| SW setting | Auto Setup | INPUT SEARCH |
| Suspend | No signal to Poweroff | |
| Picture mode | Dynamic、Standard、Cinema、Blackboard、Colorboard | |
| Lamp mode | NORMAL,ECO | |
| Filter Cleaning Cycle | 200/500/1000 hours | |
| Cooling time | 0S,60s | |
| D-Zoom | 300% | |
| Others | Customizable multi-function keys | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 345*261*99 | |
| Net. Weight (KG) | ~3.1 | |
| Packaging (WxHxD mm) | 442*368*195 | |
| Gross. Weight (KG) | 4.5 | |
| Accessory | ||
| Standard Accessaries | Power cord, HDMI cable, Remote control | |
